How to choose ECU 0281031351 55265680
Virgin Plug & Play
The Virgin version works with no faults: once connected it pairs itself with the immobiliser and vehicle, with no immobiliser programming. IMMO OFF also starts the engine, but leaves an immobiliser fault and a red warning on the dashboard that disappears only after programming the immobiliser – that is why we recommend Virgin. Condition: matching numbers and a working immobiliser.
New ECU – what you need to know
- condition: new,
- codes itself to the vehicle and immobiliser,
- after fitting: write the injector codes with a diagnostic tester.
Warranty and services
- cloning data from your old ECU – free, on request,
- chip tuning, EGR OFF, DPF OFF – extra cost,
- warranty: 1 year.
Symptoms – diagnosis first
- the engine does not start, no injector control,
- no communication with the ECU during diagnostics,
- no power supply to the ECU although the fuses are fine,
- failure after water ingress or a short circuit in the wiring.
These symptoms can also have other causes – wiring, power supply or sensors. Run a diagnosis before buying.
How to choose the ECU
- Bosch number: 0281031351
- OEM number: 55265680
The ECU is intended for the Fiat Ducato 3.0. Compatibility is decided by Bosch number 0281031351 and OEM number 55265680 – both must be the same as on your ECU. Different number? Check 0281031352 / 55262543, 0281031352 / 55265679, 0281010486 / 1327518080, 0281031351 / 55262544.
See also the other items in the Fiat Engine Control Units (ECUs) category.
FAQ: Fiat Ducato, ECU 0281031351
How does IMMO OFF differ from Virgin?
With IMMO OFF the vehicle runs, but an immobiliser fault and a red warning on the dashboard remain – only immobiliser programming removes them. Virgin has no such fault.
|
Can I transfer data from my old ECU?
Yes, cloning on request is free – send your damaged ECU or its files.
|
What is the warranty on the new ECU 0281031351?
The new ECU has a 1-year warranty.
|
