IAW 6LPB 9662402080 Virgin ECU Engine Controller for Peugeot Citroën – Ready for Adaptation
This IAW6LPB ECU engine controller with part numbers 9662402080 / 9659580780 has been professionally prepared in Virgin condition (fully reset). All previous vehicle data has been cleared, allowing the unit to function like a brand-new module and be matched to your car.
The ECU has been bench-tested and is covered by a warranty. A reliable solution when the original unit is faulty and cloning is not possible.
Key details
- Model: IAW 6LPB
- Part numbers: 9662402080 / 9659580780
- Condition: used, fully tested
- Version: Virgin – reset and cleared
- Ready for vehicle adaptation
- Start-up warranty included
Compatibility (by part number)
Suitable for PSA group vehicles – Peugeot and Citroën – equipped with petrol engines controlled by IAW6LPB.
- Peugeot 207 – 1.4 / 1.6 VTi (approx. 2006–2012)
- Peugeot 308 – 1.4 / 1.6 VTi (2007–2013)
- Peugeot 301 – 1.6 VTi
- Citroën C3 – 1.4 / 1.6 VTi
- Citroën C4 – 1.6 VTi
- Citroën C-Elysée – 1.6 VTi
Typical engine codes: EP3, EP6 (VTi petrol engines). Important: Always match by ECU part number – 9662402080 / 9659580780.
Common failure symptoms of IAW6LPB ECU
- no communication with ECU
- engine does not start despite correct wiring
- immobilizer errors / synchronization issues
- irregular engine operation or limp mode
- no injector or ignition control
- random sensor-related fault codes
What does Virgin version mean?
The ECU has been reset and cleared of all previous vehicle data:
- immobilizer data removed
- memory fully reset
- no VIN assigned
After installation, the unit must be adapted to the vehicle – just like a new ECU from the factory.
Adaptation – how it works (short overview)
To start the vehicle, ECU matching is required:
- diagnostic tools: Lexia / DiagBox
- procedure: ECU programming + immobilizer synchronization
- time: typically a few minutes
If adaptation is not possible on your side, we also offer cloning service (Plug & Play).
Why choose this unit?
- tested and verified ECU
- Virgin version ensures maximum compatibility
- cost-effective alternative to a new module
- reliable operation after proper adaptation
FAQ – Frequently Asked Questions
Does IAW6LPB 9662402080 fit Peugeot 308 1.6 VTi EP6?
Yes, as long as the ECU part number matches (9662402080 or 9659580780), it is compatible.
Is 9659580780 ECU for Citroën C4 1.6 VTi plug and play?
No, this is a Virgin unit and requires adaptation using diagnostic equipment.
IAW 6LPB 9662402080 Peugeot 207 1.4 – does it need programming?
Yes, immobilizer matching and configuration are required.
Will 9662402080 Peugeot 301 1.6 start without coding?
No, the ECU must be synchronized with the vehicle.
IAW6LPB 9659580780 Citroën C3 EP3 – can it be cloned?
Yes, if the original ECU communicates correctly, cloning Plug & Play is possible.
Does 9662402080 ECU fit different Peugeot and Citroën models?
Yes – compatibility depends on the ECU part number, not just the car model.
Which tool is needed to adapt IAW6LPB 9659580780?
Lexia / DiagBox is recommended for PSA vehicles.
Peugeot 207 1.6 VTi IAW6LPB – no ECU communication, is it faulty?
Yes, this is a common symptom of ECU failure.
Will 9659580780 Citroën C-Elysée 1.6 VTi fix immobilizer issues?
Yes, after correct adaptation it will operate like a new unit.
IAW6LPB 9662402080 – what are typical failure signs?
No start, ECU errors, no communication, or limp mode operation.
