28298209 BG91-12A650-PE ECU ENGINE CONTROLLER DCM3.5 FORD BG9112A650PE

DELPHI

Engine Control Unit Ford 28298209 BG91-12A650-PE DCM3.5 | BG9112A650PE

Original, tested Ford DCM3.5 BG91-12A650-PE engine control unit, prepared for PATS programming using IDS or Forscan diagnostic tools.

Go to full description
Fast delivery of ECU engine unit – within 1–2 working days
English / €
with VAT without VAT
Price €188.91
incl. 23% VAT

Shipping costs are not included in the price.

Shipping from €42.50 - UPS express delivery around world (Afghanistan)

express delivery 3-6 days
pcs
Availability:
available
Ask about the product

info

Information

  • CAR MODEL FORD
  • ENGINE 2.0 TDCI
  • OEM: BG91-12A650-PE
  • PART NUMBER 28298209 DCM3.5
  • VARIANT ready for programming
  • WARRANTY 6 MONTH
  • TESTED Second hand product
  • PAYMENT: Credit Card , Bank Transfer , PayPal
  • EXPRESS DELIVERY – in EU Countries: European Union 2-3 working days
  • INTERNATIONAL DELIVERY – Outside EU Countries: Worldwide 4-7 working days

description

Engine Control Unit Ford BG91-12A650-PE DCM3.5 | Engine computer 28298209 BG9112A650PE

We offer an original Ford engine control unit BG91-12A650-PE (references: 28298209, BG9112A650PE, type DCM3.5) – an engine ECU used in selected Ford diesel models. The unit has been tested electronically and for communication, so it is ready for further programming to your vehicle.

If the numbers on your ECU are the same BG91-12A650-PE / BG9112A650PE / 28298209, this engine computer will be the correct replacement.

Condition – tested and ready for programming

  • Original Ford DCM3.5 engine control unit – used part removed from a running vehicle.
  • Tested on a test bench – power supply, CAN lines, communication and memory checked.
  • Prepared for programming – requires pairing with the immobiliser and configuration for your vehicle.

DCM3.5 ECU programming – required after installation

DCM3.5 ECUs used in Ford vehicles do not work in plug & play mode. After installation, PATS programming and immobiliser pairing are necessary. This procedure is usually carried out using:

  • Ford IDS – official Ford service software with full PATS and PCM configuration support,
  • Forscan with a compatible HS-CAN / MS-CAN interface,
  • Professional diagnostic tools (Autel, Launch, Jaltest) in versions supporting PATS programming.

Example programming procedure

  1. Remove the faulty ECU and install the BG91-12A650-PE / BG9112A650PE in its place.
  2. Connect a diagnostic tool and perform engine ECU identification.
  3. Enter the PATS / Immobiliser functions and carry out ECU initialization and key programming.
  4. If necessary, perform ECU configuration (equipment options, gearbox type, etc.).
  5. Clear stored fault codes, start the engine and carry out a road test to verify correct operation.

The entire procedure should be performed by a workshop experienced in Ford ECU programming.



Question: Will the BG91-12A650-PE (28298209) ECU fit my Ford?
Answer: The most important thing is the match of the numbers on the label. If your ECU is marked BG91-12A650-PE, BG9112A650PE or 28298209 and type DCM3.5, this engine computer will be the correct replacement.

Question: Is this ECU plug & play?
Answer: No. The DCM3.5 BG91-12A650-PE ECU requires PATS programming and immobiliser pairing after installation. Without this procedure, the engine will not start.

Question: Which tool can be used to program the BG9112A650PE ECU?
Answer: Programming can be carried out using Ford IDS, Forscan with a suitable HS/MS-CAN interface or professional diagnostic tools (Autel, Launch, Jaltest) that support PATS functions and PCM configuration.

Question: Can I program the ECU myself at home?
Answer: Due to the need for correct immobiliser handling and vehicle configuration, we recommend that ECU programming is performed by an experienced workshop specialising in Ford electronics.

Question: Can I return the ECU if it does not fit?
Answer: Yes, returns are possible in accordance with the store’s terms and applicable regulations. However, before purchasing, it is always worth checking the ECU numbers carefully and, if needed, sending us a photo of the label for verification.

Electronic Car Parts FAQ – ECUSALE

1. Are the electronic modules tested before shipping?

Yes. Every electronic module, including ECU ENGINE CONTROLLERS, ABS pumps, BSI, BCM, comfort modules, transmission controllers and other automotive electronics, is electronically tested before shipping. We verify communication, power supply and basic operation to ensure the product is working correctly before delivery. This allows you to receive a tested and ready-to-install unit.

2. Does the module require programming or coding after installation?

It depends on the product version and the type of module. We offer VIRGIN, IMMO OFF and Plug & Play solutions. Information about programming or coding requirements is always included in the product description. In many cases, installation is possible without additional coding, while some modules may require adaptation using diagnostic equipment.

3. How can I choose the correct module for my vehicle?

The most important step is comparing the part numbers from your original module. Please check the Bosch, Siemens, Magneti Marelli, Continental or OEM manufacturer numbers on the label. If you are unsure, you can send us a photo of your original module or your vehicle VIN number and we will help verify compatibility.

4. Are the products covered by warranty?

Yes. All electronic automotive modules sold in our store are covered by warranty. Every product is checked and prepared before shipping. If any problem occurs, we also provide technical support and product diagnostics assistance.

5. Which payment methods are available in your store?

We offer secure online payments through Stripe and PayPal. Customers can pay using credit or debit cards, Apple Pay, Google Pay, Klarna, online bank transfers and other secure payment methods. After placing an order, you will receive a secure online payment link.
