Bosch EDC17C49 55255607 engine control unit for Fiat Ducato 2.0 Multijet 115
The offered 55255607 0281030093 engine control unit is a genuine Bosch EDC17C49 ECU designed primarily for the Fiat Ducato 2.0 Multijet 115. The module has been thoroughly inspected, tested for communication and correct operation, and is supplied with a warranty.
The control unit has been prepared as VIRGIN Plug & Play. After installation in the vehicle, the module automatically adapts to the vehicle’s immobiliser system. There is no need to copy data from the original control unit or carry out additional ECU programming.
Applications of the 55255607 0281030093 control unit
The Bosch 0 281 030 093 control unit is used mainly in Fiat Ducato commercial vehicles equipped with the 2.0 Multijet II diesel engine:
- Fiat Ducato 250 – 2.0 Multijet 115
- engine capacity: 1956 cc
- engine power: 85 kW / 115 HP
- engine code: 250A1000
- most commonly found in vehicles from 2013–2014
- control unit type: Bosch EDC17C49
The 0281030093 number may also appear in listings for the related Peugeot Boxer and Citroën Jumper models. However, the ECU must not be selected solely by vehicle model, engine capacity or housing appearance. Installation is possible only when the number on the original control unit matches 55255607 and 0281030093.
VIRGIN Plug & Play – installation without cloning
The unit has been prepared as VIRGIN, which means that the data from the previous vehicle has been cleared. After correct installation, the control unit automatically synchronises with the vehicle’s electronics during the first start-up. This eliminates the need to send the original ECU for cloning.
- no immobiliser data from the previous vehicle,
- no need to copy the memory from the original control unit,
- automatic adaptation after installation,
- control unit tested before dispatch,
- product prepared for direct installation.
Important: before purchasing, compare all complete references shown on the label of the original control unit. The most important numbers are 55255607, 0281030093 and the Bosch reference 0 281 030 093.
Possible symptoms of a faulty Bosch EDC17C49 ECU
Replacing the engine control unit may be necessary if the vehicle displays symptoms such as:
- no diagnostic communication with the engine control unit,
- the engine cranks but does not start,
- the vehicle stalls while driving or runs irregularly,
- no control of the fuel injectors or fuel pump,
- internal control unit faults that cannot be cleared,
- damage to the power supply or CAN communication circuits,
- connector corrosion, damaged pins or signs of moisture inside the ECU.
Before replacing the ECU, also check the electrical system, fuses, ground connections, power supply to the control unit and the condition of the engine wiring harness. Electrical faults may cause symptoms similar to ECU failure.
Optional IMMO OFF version
On request, the 0281030093 control unit can also be prepared in an IMMO OFF version. After installation, the vehicle starts without programming or synchronising the ECU with the immobiliser.
With the IMMO OFF version, a permanent immobiliser fault or warning message may remain stored in the vehicle or displayed on the instrument cluster. This does not affect engine starting or operation.
Frequently asked questions – 55255607 0281030093
Does the 55255607 control unit fit the Fiat Ducato 2.0 Multijet 115?
Yes. The 55255607 ECU is intended primarily for the Fiat Ducato 250 with the 2.0 Multijet 115 HP engine and engine code 250A1000. Before purchasing, confirm that the Bosch number 0281030093 matches the original module.
Does the Bosch 0281030093 work without cloning the original control unit?
Yes. The offered Bosch 0281030093 control unit has been prepared as VIRGIN Plug & Play. After installation, it automatically adapts to the vehicle’s electronics, so copying data from the original ECU is not required.
Does the 0 281 030 093 ECU fit a Peugeot Boxer or Citroën Jumper 2.0?
Compatibility with the Peugeot Boxer and Citroën Jumper must be confirmed using the complete number of the original control unit. If the original module carries the references 0 281 030 093, 0281030093 and 55255607, this control unit may be suitable. The vehicle model and engine capacity alone are not sufficient for correct selection.
What symptoms can a faulty 55255607 EDC17C49 control unit cause?
Typical symptoms include loss of diagnostic communication, inability to start the engine, intermittent stalling, lack of injection control, internal ECU faults and problems caused by connector corrosion or damaged pins.
Can the 0281030093 control unit be ordered in an IMMO OFF version?
Yes. The IMMO OFF version is available on request. The vehicle then operates without immobiliser programming, although a permanent fault related to the start authorisation system may remain displayed on the instrument cluster or stored in the vehicle’s memory.
