BCM 1361402080 503440270102 – Comfort Module for Fiat Ducato, Peugeot Boxer and Citroen Jumper
BCM 1361402080 / 503440270102 Magneti Marelli NBC250C.00 is a Body Computer / comfort module used in Fiat Ducato III, Peugeot Boxer II and Citroen Jumper II commercial vehicles. The module controls multiple body functions, communicates with the vehicle electrical system and cooperates with the immobilizer system.
The offered module is fully tested and prepared for installation after proper programming or cloning. Replacing only the BCM without adaptation is usually not enough – the module must be matched to the vehicle configuration.
Part Numbers
- 1361402080
- 503440270102
- NBC250C.00
- Magneti Marelli
Application
- Fiat Ducato III – mainly model years around 2006–2011
- Peugeot Boxer II – mainly model years around 2006–2011
- Citroen Jumper II – mainly model years around 2006–2011
The module may be installed in vehicles equipped with 2.2 HDI / JTD, 2.3 JTD / Multijet and 3.0 JTD / HDI engines depending on vehicle equipment version. Before purchase, always compare the labels and part numbers: 1361402080 and 503440270102.
When Can the BCM Module Be Faulty?
- no communication with Body Computer / BSI / BCM module,
- central locking, lighting or indicator problems,
- water damage inside the module,
- immobilizer or key recognition issues,
- incorrect operation of wipers, lights, relays or ignition power supply,
- CAN communication errors in Fiat Ducato, Peugeot Boxer or Citroen Jumper.
Programming and Cloning
This module requires programming or cloning. We can provide cloning service after receiving the original unit. Immobilizer data and vehicle configuration can then be transferred to the replacement BCM, making installation easier and reducing the risk of starting problems.
If the old BCM still communicates and data reading is possible, the best solution is usually cloning the 1361402080 / 503440270102 module. If the original module has no communication, individual diagnostics and adaptation procedures may be required.
Main Information
- original Magneti Marelli BCM module,
- used, tested and verified part,
- warranty included,
- coding, adaptation or cloning required,
- cloning possible after sending old BCM,
- part selection based on numbers 1361402080 and 503440270102.
FAQ – BCM 1361402080 503440270102 Fiat Ducato Boxer Jumper
Does BCM 1361402080 503440270102 fit Fiat Ducato III?
Yes, the 1361402080 / 503440270102 BCM module was used in selected Fiat Ducato III versions. Before purchase, compare the numbers from the original module because part number compatibility is more important than vehicle model alone.
Does comfort module 503440270102 fit Peugeot Boxer 2.2 HDI?
The 503440270102 NBC250C.00 module may fit selected Peugeot Boxer 2.2 HDI versions, but compatibility must be confirmed using the BCM number. Different Body Computer versions were used in these vehicles.
Does BCM 1361402080 work in Citroen Jumper 2.3 HDI?
The 1361402080 BCM can be found in Citroen Jumper II vehicles, including versions equipped with HDI diesel engines. The safest solution is to compare numbers 1361402080, 503440270102 and NBC250C.00 with the original module.
Is this BCM module Plug & Play?
No. The 1361402080 503440270102 module requires programming, adaptation or cloning. We can prepare the module after receiving the old BCM for cloning.
Can Magneti Marelli NBC250C.00 BCM be cloned?
Yes, in many cases cloning of Magneti Marelli NBC250C.00 BCM is possible. The original module is required to transfer immobilizer data and vehicle configuration.
What are the symptoms of faulty BCM in Fiat Ducato?
A faulty BCM in Fiat Ducato may cause central locking problems, lighting faults, immobilizer issues, CAN communication errors or complete loss of diagnostic communication. Before replacing module 1361402080, power supply and vehicle wiring should also be checked.
Does part number 1361402080 need to be identical?
Yes, it is strongly recommended to match both 1361402080 and Magneti Marelli number 503440270102. Similar housing appearance does not guarantee compatibility.
Will Peugeot Boxer start after replacing BCM?
Installing a used BCM without adaptation is usually not enough. In Peugeot Boxer, module 503440270102 works together with the immobilizer and should be coded or cloned from the original unit.
Does the offered BCM module include warranty?
Yes, the 1361402080 / 503440270102 module is fully tested and covered by warranty. Correct programming, cloning and proper vehicle electrical installation are required for successful operation.
