How to match the 0281017727 / 4L1910401J ECU to your Audi Q7 3.0 TDI
Bosch 0281017727 is an EDC17CP44 unit – the newer generation of electronics used in the Audi Q7 3.0 TDI (4L); its housing carries the Audi number 4L1910401J. We supply it as IMMO OFF Plug & Play, tested in a car; the warranty is 6 months.
Label markings
- Bosch number: 0281017727 (0 281 017 727)
- Audi number: 4L1910401J (4L1 910 401 J)
- ECU type: Bosch EDC17CP44
Vehicle compatibility
The label decides, not the model year: the Bosch number 0281017727 and the Audi number 4L1910401J must be the same as on your ECU. If your Q7 version is not mentioned in the description, the unit may still fit. Watch out for similar numbers – 0281016835 (4L1910401L) has different software and is not a replacement, and earlier Q7s with EDC16CP34 (e.g. 0281013691) use a different ECU type.
Preparation and installation
The 0281017727 unit is prepared as IMMO OFF and the engine starts without programming. On EDC17, however, an immobiliser fault remains stored and cannot be cleared. In a Q7 with the large-display instrument cluster the message SAFE appears; with the smaller display there is no message. If you want the car to run without this fault, have a workshop carry out an immobiliser adaptation or order data cloning from your old ECU (included in the price). Paid options: DPF OFF, EGR OFF, FLAPS OFF, chip tuning.
Symptoms of a failed ECU in the Q7
A typical cause of failure in the Q7 is water from the scuttle area where the ECU is mounted. Signs of damage include:
- the radiator fans run constantly with the ignition on
- the engine stalls when warm or after contact with moisture
- corrosion on the pins or the circuit board
Before buying, rule out the power supply, wiring and battery, as they cause similar symptoms. Read more here: water-damaged EDC17 ECU in the Audi Q7 3.0 TDI.
Other Audi Q7 3.0 TDI ECUs in stock
Full range: Audi engine ECUs · Bosch ECUs
Frequently asked questions about the 0281017727 / 4L1910401J ECU
Will an immobiliser fault remain after fitting the 0281017727?
Yes. On EDC17 units the IMMO OFF version leaves an immobiliser fault that cannot be cleared. A cluster with the large display shows SAFE; the smaller display shows no message. The engine starts and runs normally.
|
Does the 0281017727 need programming?
No – the IMMO OFF version starts the engine without programming; only the immobiliser fault described above remains.
|
What extra options can I order with the 0281017727?
Paid options: DPF OFF, EGR OFF, FLAPS OFF and chip tuning.
|
